Mat.No. 1.0715, DIN 9SMn28, AISI 1213

Short Description:

Designation by Standards Mat. No. DIN EN AISI 1.0715 9SMn28 - 1213 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others max. 0.14 max. 0.05 1.10 - - - - - S = 0.30 Description Non alloy quality steels. Steel with higher S content. Applications Free-cutting steel, case-hardening steel. Serial production elements for vehicles, devices, plants. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/m...

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Port: Shenzhen

Payment Terms: L/C,D/A,D/P,T/T

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Designation by Standards

Mat. No.	DIN	EN	AISI
1.0715	9SMn28	-	1213

Chemical Composition (in weight %)

C	Si	Mn	Cr	Mo	Ni	V	W	Others
max. 0.14	max. 0.05	1.10	-	-	-	-	-	S = 0.30

Description
Non alloy quality steels. Steel with higher S content.

Applications
Free-cutting steel, case-hardening steel. Serial production elements for vehicles, devices, plants.

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [10³ x N/mm²]: 210
Density [g/cm³]: 7.85

Core Hardening
Harden from a temperature of 880-920^oC followed by water quenching.

Tempering
Tempering temperature: 150-200^oC.

Forging
Hot forming temperature: 1050-850^oC.

Machinability
No data.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.

Unless otherwise specified, registered trademarks are property of Metal Ravne company. Copyright 2015 by Metal Ravne. All rights reserved. Contact our Sales Office for more information.
