Mat.No. 1.5026, DIN 55Si7, SAE 9255

Designation by Standards

Chemical Composition (in weight %)

Description
Special structural steel.

Applications
Steel for worm and laminated springs thickness up to 7 mm for trucks and railway vehicles, safety washer plates, coiled springs.

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [10³ x N/mm²]: 210
Density [g/cm³]: 7.80

Soft Annealing
Heat to 640-680^oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 245.

Normalizing
Temperature: 830-860^oC, air.

Hardening
Harden from a temperature of 830-860^oC followed by oil quenching.

Tempering
Tempering temperature: 350-550^oC, air.

Forging
Hot forming temperature: 1050-850^oC.

Machinability
No data.

Forms manufactured: Please see the Dimensional Sales Program.
