4145H steel

Short Description:

Description AISI 4145H 120 KSI Alloy Steel Bar for Drilling Collar, Drill Pipe, Square Kelly, Lifting Sub, Stabilizer Chemical Composition (%) C Si Mn P S Cr Mo Ni Cu 0.42 0.49 0.15 0.35 0.80 1.15 ≤ 0.020 ≤ 0.025 0.75 1.20 0.15 0.45 ≤ 0.25 ≤ 0.30 Dimensions Hot Rolled Forged Diameter (mm) 50-130 100-1300 Length (mm) 4000-10000 3000-10000 Delivery Condition EAF+LF+VD, Hot Rolled or Forged, Machined, Q+T, UT 100% P...

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Port: Shenzhen

Payment Terms: L/C,D/A,D/P,T/T

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Description

AISI 4145H 120 KSI Alloy Steel Bar for Drilling Collar, Drill Pipe, Square Kelly, Lifting Sub, Stabilizer

Chemical Composition (%)

C	Si	Mn	P	S	Cr	Mo	Ni	Cu
0.42 0.49	0.15 0.35	0.80 1.15	≤ 0.020	≤ 0.025	0.75 1.20	0.15 0.45	≤ 0.25	≤ 0.30

Dimensions

	Hot Rolled	Forged
Diameter (mm)	50-130	100-1300
Length (mm)	4000-10000	3000-10000

Delivery Condition

EAF+LF+VD, Hot Rolled or Forged, Machined, Q+T, UT 100% Passed

Mechanical Properties

	Tensile Strength PSI (MPa)	Yield Strength PSI (MPa)	Elongation	Reduction of Area	Hardness
Min.	140000	120000	14%	45%	30 HRC (285 HB)
Max.	——	——	——	——	36 HRC (341 HB)

Characteristics

AISI / SAE 4145H grade is a low-alloy steel containing chromium and molybdenum as strengthening agents. The steel has good fatigue strength and impact toughness in low temperature, weldability and machinability.
